Pace 500 ebike

Size Guide

Color
Deep Black
Size
28 mph max speed on pedal assist and throttle

28 MPH

On Pedal Assist, 20 MPH on Throttle

40 miles range per charge

Avg. 40 Miles

Range Per Charge

750W (peak) 500W (sustained) brushless hub motor

750W Motor

750W Peak Brushless Motor

Hydraulic Disc Brakes with Safety Cut Off Sensor
Hydraulic Disc Brakes with Safety Cut Off Sensor

Hydraulic Brakes

Hydraulic Disc Brakes w/ Safety Cut Off Sensor

Cushy Saddle

Comfortable Wide Saddle for Long Rides

Big LCD Display

Backlit Easy Read LCD Screen

  • Powerful 750W (Peak) 500W (Sustained) Brushless Motor

  • 25-40 Estimated Mile Range Per Charge (Samsung Battery)

  • Max Speed 28mph (45kph)

  • Hydraulic Disc Brakes w/ Safety Motor Cut-Off Sensor

  • Battery Charger Included

  • LCD Smart Display

  • 27.5" E-Bike Rated Tires for Safety and Comfort

  • 30-Day Hassle-Free Return Policy

Keep up the Pace with our latest ebike! This 28mph Class III ebike maximizes fun and keeps you cruising. It's like powering up your legs to make hills a thing of the past. Equipped with large comfortable tires, the Pace gives you the ultimate balance in comfort and power. With a relaxed, upright riding position and 5-levels of pedal-assist, this ride will keep the smile on your face all day long.

“It's amazing that this bike comes at such an affordable price”
Click again to read full review Click again to read full review Click again to read full review Click again to read full review
Press for Aventon Pace 350
“affordable yet powerful and versatile high speed ebike which gives more bang for your buck”
Click again to read full review Click again to read full review Click again to read full review Click again to read full review
Pace 500 Black Rides on the street next to the beach
Large Backlit LCD display down view

Large Backlit LCD Display

Everything you need, right at your handlebars. Monitor your charge level, speed, distance, and pedal assist level right on your screen. There's even a backlight for night rides.

woman rides bike on path next to beach

Throttle & Pedal Assist

With the Pace 500 you can ride with pedal assist or throttle. Use a little pedal assist when you want a workout, or a higher setting for help on the hills. Or use the throttle if you don't want to pedal at all.

man rides pace 500 ebike on bike path pulling trailer

Class III 28 MPH Ebike

Our powerful rear-hub motor gets you up to speed immediately, climbs hills effortlessly, and tows trailers easily

man carrying pace 500 ebike down stairs

Lightweight and simple to own

At just 49lbs, Pace 500 is light enough to load onto a car rack or carry up a flight of stairs - significantly lighter than competing ebikes.

silver Aventon badge on the head of all ebikes

Easy to assemble and maintain

Only a few minutes to build your bike and you'll be riding in no time

pace 500 ebike with rack and rack top bag

Customize your way

Easy and simple to add custom rack, fenders, or bags that fit your lifestyle and make full use of your ebikes capabilities.

Find My Size

Unlike other ebikes, we don't believe one size fits all. The fit of your bike can make or break your riding experience and we want you to stay cruising. Simply find your height and match your size. The hard part is picking a color.

S

5'1" - 5'7"

M

5'7" - 5'11"

L

5'11" - 6'4"

Full Geometry Chart

FRAME SIZE Small Medium Large
Height 5'1" - 5'7" 5'7" - 5'11" 5'11" - 6'4"
A | Effective Top Tube Length^ 592mm 611mm 649mm
B | Seat Tube Length C-T 380mm 440mm 500mm
C | Standover Height 676mm 731mm 780mm
D | Stack 572mm 612mm 632mm
E | Reach 349mm 355mm 381mm
F | Head Tube Angle 68° 69° 69°
G | Seat Tube Angle 62° 67° 67°
H | Fork Offset 55mm 55mm 55mm
I | BB Drop 70mm 70mm 70mm
J | Wheelbase* 1086mm 1094mm 1131mm
K | Chainstay 480mm 480mm 480mm
L | Head Tube Length 165mm 195mm 225mm

Specifications

ELECTRONICS

Motor
750W (Peak), 48V Brushless Rear Hub Motor
500W (Sustained)

Speed
Max 28 Miles on pedal assist or 20 throttle (no pedaling)

Pedal Assist
5 Levels
Battery
Lithium-ion 48V, 11.6Ah (556.8Wh) with Samsung Cells

Charger

48V 3 Amp Fast Charger, 3-4 Hour Charging


Display
LCD Smart Easy Read Display with Backlight
Sensors
Cadence Sensor

Range
25-40 Miles Estimated

Frame and accessories

FRAME

Frame
6061 Double-Butted Aluminum Alloy

Fork
6061 Aluminum Alloy, tapered


Build

Weight
49lbs

Weight Limit
Maximum Rider Weight: 250lbs
Cargo Capacity: 50lbs

aCCESSORIES

Pedals
9/16" Alloy Platform

Drivetrain & Brakes

Bottom Bracket
Square Tapered, Sealed

Cassette
Shimano Altus 11-32 Cassette, 8 Speed

Chain
KMC Z Series, 8 Speed
Crankset
170mm w/ 42 T

Shift Levers
Shimano 8 Speed Altus

Rear Deraileur
Shimano Altus 8 Speed
Brakes
Tektro HD-T285 Hydraulic Disc Brakes w/ 180mm Rotors

Wheels & Tires

Rim
Double Wall Aluminum 36h Front & Rear

Hub
Joytech 36H Disc Nutted Front and Rear

Spokes
Black Stainless

Tires
27.5" x 2.2" Kenda Kwick Seven Sport, Ebike
Tubes
Butyl Rubber, Schrader Valve

Contact Points

Saddle
Aventon Velo Comfort, Steel Rails, 245mm wide

Seat Clamp
Quick Release

Grips
Ergonomic Comfort
Seatpost
Forged Alloy, 31.6mm, 2-Bolt Clamp

Handlebars
Aluminum 31.8 15 Degree Sweptback

Stem
Threadless, Adjustable 31.8mm
Headset
VP Sealed Bearing Headset

Additional Information

Pace 500 ships as a Class III ebike, with up to 28 MPH on pedal assist and 20 MPH on throttle. If you are riding on private property or in an area without ebike speed restrictions, the speed limit can be modified in the settings, and Pace 500's powerful motor can go up to about 32 MPH on pedal assist. Pace 500 will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are not allowed.



Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means it’s OK to ride or park your ebike in the rain. It won’t be harmed by spray from a wet road or raindrops. Your ebike is not intended to be submerged or subjected to a pressurized spray. Don’t use a pressure washer or sprayer to clean your ebike.
